Description
HY-LS6000 Desktop Magnetic Pump Automatic Filling Machine
Desktop magnetic pump automatic single-head liquid filling machine, utilizing magnetic pump technology, offers stepless adjustable filling speed and sets filling volume by controlling filling time. Suitable for non-viscous and low-viscous liquids. features a conveyor for bottle feeding, photoelectric bottle detection, automatic filling, and bottle comeout upon completion. The control panel is digitally operated. This compact and flexible desktop automatic filling machine is ideal for various types of liquids.
Product application
Table top liquid filling machine, fruit juice filling machine, beverage filling machine, drinking water filling machine, olive oil bottle filler, edible oil filling machine, engine oil filling machine, pesticide filling machine, essential oil dispensing equipment, aromatherapy liquid filling machine, etc.HY-LS6000 Tabletop Magnetic Pump Automatic Filling Machine
Technical Parameters
Model
Heads
1pc
Filling Pump
Capacity(BPH)
Volume
Accuracy
Suitable Bottles
Height: 50-250mm, Diameter: Φ20-150mm, (can be customized)
Control method
Maximum suction distance
Max load
Maximum flow
Power supply
Voltage
Weight
Machine Dimension
Machine Dimension
HY-LS6000
Stainless Steel Magnetic Pump
150~1800 according to filling amount and liquid
1ml-3000ml customized
≤±1%
Digital panel
2 Meters
5Kg
3 Liters/minute
300w
110V/220V/1P 50/60Hz, customized globally
24Kg
120x60x32cm
122x65x35cm
Click here to view HY-LS6000 Desktop Magnetic Pump Automatic Filling Machine running video on YouTube
