HYSR-200RP Traction Type PVA Film Pod Packaging Machine

HYSR-200RP Traction Type PVA Film Pod Packaging Machine

Product Item：HYSR-200RP

Application：Commodity, Chemical

Key Selling Points：High Productivity

Usage：Pack material in pva film

Packing material：powder, granules, liquid

Description

HYSR-200RP Traction Type PVA Film Pod Packaging Machine

Product Introduction

Automatic PVA Pod Packaging Machine adopts plc, touch screen, servo motor control, the machine operation is very stable. The machine can fill the liquid detergent or powder and form the four sides bag directly, the bag of four sides is accurate, the machine packing speed is fast and the finished bag is beautiful. The machine adopts Touch screen and PLC programmable control, photoelectric sensing, Adopt the stable reliable electrical components, make the machine run stable and easy to operate. This machine adopts vacuum film absorption, multi-cavity quantitative filling at the same time, upper and lower double film water seal sealing, edge cutting with round corner hot knife, automatic decoating and beading, conveying box. The ring is formed by self-circulating die and tooling Shape flexible production line continuous production. Through data acquisition, intelligent measurement and control and Internet of things platform technology to achieve remote production monitoring, operation and maintenance, life cycle management.

Product Application

PVA water soluble film as packing material. Finished products listed like detergent beads, laundry detergent pod, floor cleaning liquid pods, toilet bowl cleaner powder beads, dish washing powder pva capsules, laundry liquid and granules beads, and other chemical pods.

HYSR-200RP Flat Plate Traction Type PVA Water-soluble Film Pod Packaging Machine

Technical Parameters
Mould cavity arrangement	according to pod chambers
Packing material	Anhydrous formula detergent, powder, granules
Packing speed	5000-8000 bags/hour
Volume	5-30 grams by changing mold
Voltage	AC380V/220V/415V, three phases, Globally customized
Power	10kw
Pneumatic	0.6-0.8mpa
Roll film material	PVA Polyvinyl alcohol, PVOH
Mold replacement time	30 ~ 60 minutes
Machine size	L369xW92xH210cm
Remarks	The parameters are different according to specific gram weight, shape, specification and material properties. The equipment is equipped with automatic film bonding system.

Main Features


The mold adopts integrated traction design. After training, customers can quickly replace the mold. When changing different packaging shapes, they only need to replace the mold and adjust the corresponding pipeline. The corresponding program and gram weight (monochrome, double color, three color or multi color) are selected on the touch screen. The pipeline connected with the material is a clamp-type quick joint, which is simple and convenient to operate. After training, the replacement can be completed. Other manufacturers need to send professionals to replace the mold, or even return to the factory for renovation.
The liquid filling system is a gravity filling system, which has a wide adjustment range of ml volume. The filling quantity is controlled by controlling the time of filling valve. The filling precision is good for liquid with good mobility. The filling head is designed to meet the packaging requirements of single cavity, double cavity, three cavities and customized for more chambers. The maintenance is simple. Each cavity corresponds to a filling head, so the adjustment of ml volume is convenient and flexible. Powder and granules dosing use cup volume measurement.
After packaging and molding, the slitting device is a slitting system, which ensures reliable and stable slitting. The equipment can run continuously for a long time. The equipment is unreliable and cumbersome to maintain.
The liquid replacement operation is simple, which can be completed within a few minutes and can be completed in the operation interface without disassembling the pipeline;
The unwinding of the bottom film and the top film is controlled, the tension is constant, and the size and plumpness of the produced beads are stable; The sealing form is water seal+electrical heating seal. The precision is extremely high.
