HYTB-150S-B Automatic 1 Gallon to 10L Round Barrel Self-adhesive Sticker Labeling Machine | Vertical Bottle Label Applicator

HYTB-150S-B Automatic 1 Gallon to 10L Round Barrel Self-adhesive Sticker Labeling Machine | Vertical Bottle Label Applicator

Product Item：HYTB-150S-B

Control: PLC Touch screen

Machinery Capacity: 3000BPH

Key Selling Points: High-accuracy

Marketing Type: Ordinary Product

Description

HYTB-150S-B Automatic One Gallon to Ten Liters Round Bottles Vertical

Self-adhesive Sticker Labeling Machine

Product Introduction
Automatic Vertical Big Round Bottle Self-adhesive Sticker Labeling Machine can stick non-dry sticker label for round bottle. With inspection of sensor, tracking label synchronously, ensure to labeling speed and smoothly.
Host design labeling machines using imported and domestic advanced technology to improve and make a solution for instability of general domestic labeling. By optical fiber computer control, we can get the synchronization track. The output of labels is controlled by a stepper motor or servo motor. It can detect the objects and size of labels automatically. It is modern and advanced electromechanical integration equipment automatically controlled by microcomputer mode, with large LCD touch panel, display and memory devices containing dozens of memory devices. The operation is simple, the labeling is accurate, the performance is reliable, and there is low noise. Sticker labeling machine is easy to clean, not moldy, beautiful after labeling and of high production efficiency. It is strong and won't fall off on its own.

Application
1 gallon round bottle labeling machine, 5 liters round barrel label applicator, 10 liters round barrel sticker labeller, one gallon cooking oil pet barrel labeling machine, 5 liters shampoo barrel label applicator, 10 liters edible oil barrels label application machine, etc.

HYTB-150S-B Automatic One Gallon to Ten Liters Round Bottles Vertical Self-adhesive Sticker Labeling Machine

HYTB-150S-B Automatic Cooking Oil Round Barrel Labeling Machine

Technical Parameters
Labeling capacity	0-50pcs/min
Labeling accuracy	±1.0 mm
Label material	Adhesive sticker, opaque or transparent label
The inner diameter of label roll	76 mm
The outer diameter of label roll	350 mm(max)
The suitable size of label	Width 20-200 mm length 15-300 mm
The suitable size of labeling objects	Can be customized
Operating direction	Left or Right
Total Power	1.5kw
Power supply	AC220V/110V, Single phase. Globally customized
Net weight	About 280kg
Machine size	200(L)×80(W)×100(H)cm
Optional device	Ribbon coder, transparent label detecting sensor
