Description
HYYG-200B Automatic Bottle Pressing-on Capping Machine
The machine use the straight line into the bottle, automatically arrange caps, sleeving caps, caps after sleeve and check will go into the gland system by the clamping belt. Due to the slant track design have a drop of slop, the caps after press will become more and more tightly.The machine has simple structure, convenient adjustment, production speed fast, high pass rate, after cap pressing has good performance, suitable for cap pressing of foodstuff, soy sauce, vinegar, vegetable oil's bottle shape.
Product Application
Automatic bottle capping machine, gland capping machine, pressing-on bottle lid capper, automatic bottle capper, automatic bottle capping equipment, cooking oil bottle capping machine, soy sauce bottle capping machine, vinegar bottle automatic capper, powder bottle capping machine, etc.
Technical Parameters
Capping capacity
2000-6000 bottles/hour
Applicable cap diameter
20-60mm customized according to caps
Suitable bottle diameter
customized according to bottle sample
Suitable for bottle height
customized according to bottle sample
Capping method
Grand ( Pressing on )
Total Power
1.5kw
Power supply
AC380V/220V/415V, three phased, globally customized
Machine size (Main body)
120*100*180cm
Lid sorting elevator
80*80*200cm
Weight
390Kg
Main Features
1) PLC controlled, integrated cap feeding, loading & capping.2) Simple structure in linear type, easy in installation and maintation.
3) Adopting advanced world famous brand components in pneumatic parts, electric parts and operation parts.
4) High speed adjustable from 2000-6000pcs per hour.
5) Running in a high automatization and intellectualization, no pollution.
6) Economic price and suitable for both big and small capacity production.
Click here to view HYYG-200B Automatic Bottle Pressing-on Capping Machine running video on YouTube
