Automatic Plastic Soft Tube Filling Sealing Machine

Automatic Plastic Soft Tube Filling Sealing Machine

Product Item：HYGF-60

maceutical Automatic Grade: Automatic

Bottle type: Plastic tubes

Filling range: 10-400ml customized

Application: Food, Beverage, Medical, Chemical, Machinery & Hardware,

Description

Automatic Plastic Soft Tube Filling Sealing Machine

Product Introduction

Automatic tube filling and sealing machine is suitable for filling all kinds of pasty and viscous fluid and the materials alike, into plastic and composite metal tubes and then internally heating tubes, sealing and printing lot number. It is used in the industries of pharmaceutics, foodstuffs, cosmetic and daily chemicals . With touch screen and the PLC control system employed, convenient, visualized and reliable non-touch operation of the machine is effected compact design and auto tube feed. Driving part fully-closed.Tube feeding, marking identification, filling, hot air sealing, code printing, trimming and ejecting out the tube conducted by automatic system. Tube feeding is conducted pneumatically, accurate and reliably. Auto package effected by photoelectric inductance. Easy adjustment and dismantling .Intelligent temp.control and cooling system makes operation easy and sealing reliable. With easy and quick adjustment, it is suitable for using multiple kinds of soft tubes for filling.The part contacting materials is made of stainless steel, clean, sanitary and conforming to GMP. With safety device, the machine is shut down when the door is opened. and filling carried out only with tubes fed.

Product Application

Tube material: plastic soft tube, aluminum plastic or plastic laminate tube.

For examples: hand sanitizer gel, facial cream, facial cleaner, tooth past, hand cream, ointment, etc. Tube filling and tailor sealing machinery.

Automatic tube filling and sealing machine

Technical Parameters
Production capacity	30-60 pcs/min(Adjustable)
Tube size	Dia.5-50mm, hieght 5-200mm
Filling volume	2-400 ml
Filling accuracy	± 1%
Rejection rate	< 1%
Hopper	With mixer and heater(optional)
Hopper volume	35 L(can be customized)
Motor Power	1.1kW
Air feeding	0.37kW
Convulsions	0.37kW
Hot air power	3 kW
Compressed air	0.6-0.8 MPa
Static seal	Fluororubber seal "O"
Motive seal	SiC-S+Fluororubber seal
Dimension	200(L) x 100(W) x 180(H) cm
Net weight	Approx 500 KGS
General power supply	AC 380/220V(Optional), Single or three phases, Globally customized
