HYPL-10A-X + HYXG-4C-X Automatic Tilt Bottle Capping Machine for Toilet Bowl Cleaner
Introduction
Automatic four wheels clamping tilt bottle screwing capping machine is a new product developed on the base of the latest technology, using four wheels to clamp and screw cap of the toilet bowl cleaner bottle. The bottle sealing machine adopts PLC to combine the actions. And the parameters are set in touch screen. The mechanical parts are customized to suit for bottles with different sizes. Its most prominent feature is that it is customized for tilt bottle. According to lid types, the capping machine can be equipped with suitable cap sorting device, such as vibrating bowl, centrifuge bowl, elevating lid sorter. it can be used for medium and big-batch production.The machine meets the GMP requirements, easy to disassemble, clean and maintain. The capping machine is widely used in daily chemical industries.
Application
Toilet bowl cleaner tilt bottle capping machine, Tilt neck bottle capper for toilet cleaner, Angled bottle screwing capping machine, Inclined spout bottle capping equipment, Tilted bottle cap tightening machine, Automatic tilt bottle capper for liquid cleaner, Leak-proof capper for tilted cleaner bottles, PLC control tilt bottle capping machine, High-speed capping machine for angled bottles, Toilet cleaner packaging capping machine, etc.
|
Technical Parameters |
|
|
Capping capacity |
0-2500bottles/hour according to bottle and lid sizes |
|
Applicable cap diameter |
15-40mm customized according to cap samples |
|
Suitable bottle diameter |
20-90mm, special sizes can be customized according to bottle sample |
|
Suitable for bottle height |
80-280mm, special sizes can be customized according to bottle sample |
|
Total Power |
1.8Kw |
|
Power supply |
AC220V/110V, Single phase, can be customized globally |
|
Air supply |
0.5-0.7Mpa |
Main Features
1) Simple linear structure and four wheels clamping capping, excellent capping effect and wide adaptability, easy in installation and maintenance.
2) Use servo motor and four wheels clamping lid to screw lid with bottles, high efficiency and good effect.
3) Adopting advanced world famous brand components in pneumatic parts, electric parts and operation parts.
4) High speed adjustable from 0-2500pcs per hour.
5) Running in a high automation and intelligent, no pollution.
6) Economic price and suitable for both medium and big capacity production.
