HYB1G2P1S1-100 Automatic Turntable Driving Type Bottle Air Blowing Liquid Filling Plugging and Capping Machine

  • Product Item：HYB1G2P1S1-100
  • Machinery Capacity: 2000BPH
  • Filling Accuracy: 0.5%
  • Air pressure: 0.6~0.7Mpa
  • Marketing Type: Ordinary Product
    • nail polish bottle filling capping machine , Liquid spray bottle filling plugging capping machine
    Inquiry Send Email

    Description

    HYB1G2P1S1-100 Automatic Bottle Air Cleaning Liquid Filling

    Plug Inserting and Capping Machine


    Product Introduction

    Rotating Disk Bottle Air Cleaning Filling Plugging and Capping Machine is a mono-block machine combines bottle air blowing filling plugging and capping, applicable for various bottles and liquids, PLC computer system and touch screen controlling, filling part is driven by the servo motor, adopting the volumetric principle, which is helped to realize the high filling precision. Capping part consists of cap-feeder, cap-scratch, cap-clamping, bottle conveying and capping parts. The whole machine runs stably and reliably with high efficient and high adaptation. The above mentioned parts are made of stainless steel 304, totally matching GMP requirements.
    Rotating Disk Filling and Capping Machine is mainly used for bottling of daily chemical, agricultural chemical, food, personal care and pharmaceutics industry.

    Machine Application
    Betadine bottle filling plugging capping machine, eyedrop bottle filling capping machine, emulsion jar filling pad inserting capping machine, essential oil filling plugging capping machine, facial cream filler plugger capper, nail polish bottle filling capping machine, Liquid spray bottle filling plugging capping machine, etc.

    HYB1G2P1S1-100 Automatic Bottle Air Cleaning Liquid Filling Plug Inserting and Capping Machine

    HYB1G2P1S1-100 Automatic Bottle Blowing Filling Capping Machine

    Technical Parameters
    Production capacity
    20-35 pcs/min(Adjustable)
    Bottle size
    Width: Φ20mm~Φ60mm, height: 50mm-150mm
    Filling volume
    10-100 ml customized
    Filling accuracy
    ± 1%
    Rejection rate
    < 1%
    Electricity power
    2.6KW
    Compressed air
    0.6-0.8 MPa
    Air comsumption
    100L/M
    General power supply
    AC 380/220V(Optional), Single or three phases, Globally customized
    Dimension
    170(L) x 140(W) x 190(H) cm
    Net weight
    Approx 580 KGS
    Automatic Bottle Blowing Filling Capping Equipment

    HYB1G2P1S1-100 Automatic Bottle Blowing Filling Capping Machinery

    Automatic Essential Oil Bottle Blowing Filling Capping Machine

    HYB1G2P1S1-100 Automatic Bottle Blower Filler Capper

    HYB1G2P1S1-100 Automatic Eyedrop Bottle Blowing Filling Capping Machine

    HYB1G2P1S1-100 Automatic Small Bottle Blowing Filling Capping Machine

    Automatic Bottle Blowing Filling Capping Machine
