HYRS-S Automatic Rotary Multi-heads
Bottles Capping Machine
Product Introduction
Automatic rotary type grasping-cap capping machine automatic is integrated bottle collecting, cap arranging, cap putting on, cap rotary and bottle exiting in one machine. It uses catching cap positioning rotary cap, whole machine is rotary structure. In the process of rotary cap without injury bottle and cap phenomenon, high efficiency, high qualified rate, stable operation, wide application range. The machine is adaptable for various kinds of outer cap automatic revolve to close for regular glass or plastic bottle, the capping device grasping various caps transmitted by scraping plate, complete outer cap revolve to close in the bottle rotary process. The machine adopts PLC control, touch human-machine interface, convenient and intuitive operation.It is widely used in pharmaceutical, chemical, food, beverage, oil and pesticides industries.
Working principle of machine: Drive the rotation of main shaft from the dynamic of motor by the gear reducer; The rotation among curve camshafts is converted into the force which drives the capping head to move upward and downward; At the same time the gear reduce drives the curve camshaft in the bottom to make the star wheel move intermittently which matches up with the up-and-down movement of capping head. The upper variable speed motor let the capping head works by driving the belt; When the star wheel rotates the bottles below the capping head which punches the binding face between cap inner liner and bottle mouth; Meanwhile the fit thread screw is completed from the the flanging and rolling pilfer proof ring. Finally the perfect capping effect comes out. This machine has compact and reasonable structure, it is easy to combine other devices into its production line.
Automatic Rotary Multi-heads Plastic Lid Capping Machine is mainly used for bottling of daily chemical, agricultural chemical and pharmaceutics industry.
Product Application
Plastic cap screwing capping machine, lug twist-off tinplate metal lid capping machine, pesticide bottles capping machine, lubricant barrel capping machine, medical alcohol bottles capping machine, 1 liter motor oil bottle capping machine, Glass Bottles capping machine, 5 liter motor oil barrel screwing capping machine, medical bottles cap sealing machine, etc.
HYRS-S Automatic Rotary Multi-heads Bottles Capping Machine
