  • HYTF-100S Semi-automatic Soft Tube Filling and Ultrasonic Sealing Machine
  • HYTF-100S Semi-automatic Soft Tube Filling and Ultrasonic Sealing Machine
  • HYTF-100S Semi-automatic Soft Tube Filling and Ultrasonic Sealing Machine
  • HYTF-100S Semi-automatic Soft Tube Filling and Ultrasonic Sealing Machine
HYTF-100S Semi-automatic Soft Tube Filling and Ultrasonic Sealing MachineHYTF-100S Semi-automatic Soft Tube Filling and Ultrasonic Sealing MachineHYTF-100S Semi-automatic Soft Tube Filling and Ultrasonic Sealing MachineHYTF-100S Semi-automatic Soft Tube Filling and Ultrasonic Sealing Machine

HYTF-100S Semi-automatic Soft Tube Filling and Ultrasonic Sealing Machine

  • Product Item：HYTF-100S
  • Filling Accuracy: ±0.5%
  • Driven Type: Electric
  • Capacity: 8-12 pcs/minute
  • Filling range: 10-500ml customized
    • boots oil soft tube filler sealer , toothpaste tube filling sealing machine , hand cream filler sealer , chocolate sauce tube filling sealing machine
    Inquiry Send Email

    Description

    HYTF-100S Semi-automatic Soft Tube Filling and
    Ultrasonic Sealing Machine


    Product Introduction

    Semi-automatic Tube Filling and Sealing Machine is suitable for filling all kinds of pasty and viscous fluid and the materials alike, into plastic and composite metal tubes and then internally heating tubes, sealing and printing lot number.
    It is used in the industries of pharmaceutics, foodstuffs, cosmetic and daily chemicals . With touch screen and the PLC control system employed, convenient, visualized and reliable non-touch operation the machine is effected compact design. Manually feeding tubes, marking identification, filling, ultrasonic sealing, code printing, trimming by automatic system, manually take products.
    The part contacting materials is made of stainless steel, clean, sanitary and conforming to GMP.

    Machine Application
    Tube material: plastic soft tube, aluminum plastic or plastic laminate tube
    Filling material: ointment tube filling sealing machine, adhesives soft tube filler sealer, AB glue soft tube filling sealing machine, Neoprene plastic tube filling sealing equipment, epoxy glue  tube filling sealing machine, skin cream filling sealing machine, hair cream filling sealing machine, boots oil soft tube filler sealer, toothpaste tube filling sealing machine, hand cream filler sealer, chocolate sauce tube filling sealing machine, honey tube filling sealing machine, etc.

    HYTF-100S Semi-automatic Soft Tube Filling and Ultrasonic Sealing Machine

    Semi-automatic Soft Aluminum Plastic Tube Filling Sealing Machine

    Technical Parameters
    Production capacity
    8-12pcs/min
    Tube size
    Dia.12-50mm, height 50-220mm
    Filling volume
    A. 6-60ml, B. 10-120ml, C. 25-250ml, D. 50-500ml
    Filling accuracy
    ± 1%
    Rejection rate
    < 1%
    Filling method
    Pneumatic piston pump
    Hopper
    With mixer and heater(optional)
    Hopper volume
    35 L(can be customized)
    Power
    2Kw
    Ultrasonic frequency
    20kHz
    Station qty
    One
    Suitable tube
    Single tube
    Tube material
    Plastic composite pipe, aluminum plastic pipe
    Automatic identification system
    No pipe, no tail sealing
    Compressed air
    0.6MPa
    Dimension
    86(L) x 65(W) x 155(H) cm
    Net weight
    130kgs
    General power supply
    AC 220V/110V(Optional), Single phase, Globally customized
    HYTF-100S Semi-automatic Soft Tube Filling Sealing Machinery

    Semi-automatic Soft Tube Cream Filler Sealer

    Semi-automatic Soft Tube Filling Sealing Equipment

    HYTF-100S Semi-automatic Soft Tube Honey Filler Sealer

    Semi-automatic Soft Tube Gel Filler Sealer

    Semi-automatic Soft Tube Toothpaste Filler Sealer

    Semi-automatic Soft Tube Filling Sealing Machine
