  • Provide 50-1000ml Pneumatic Driving Piston Cylinder Dosing Filler
  • Provide 50-1000ml Pneumatic Driving Piston Cylinder Dosing Filler
  • Provide 50-1000ml Pneumatic Driving Piston Cylinder Dosing Filler
  • Provide 50-1000ml Pneumatic Driving Piston Cylinder Dosing Filler
Provide 50-1000ml Pneumatic Driving Piston Cylinder Dosing FillerProvide 50-1000ml Pneumatic Driving Piston Cylinder Dosing FillerProvide 50-1000ml Pneumatic Driving Piston Cylinder Dosing FillerProvide 50-1000ml Pneumatic Driving Piston Cylinder Dosing Filler

Provide 50-1000ml Pneumatic Driving Piston Cylinder Dosing Filler

  • Product Item:HYPF-1000P
  • Automatic Grade: Automatic
  • Packaging Material: Plastic, Metal, Glass
  • Filling volume: 50-1000ml
  • Application: Food, Beverage, MEDICAL, Chemical, Machinery & Hardware
  • Inquiry Send Email

    Description


    Provide 50-1000ml Filling MachinePneumatic Driving Piston
    Cylinder Dosing Filler



    Product Application

    Linear pneumatic driving piston filling machine is for different viscous liquid and cream with different bottle or jars. The performance of the product reaches the international leading level. PLC control, pneumatic driving, equipped with brand touch screen, smooth operation, no leakage phenomenon, No bottle no filling, automatically control feeding the liquid into machine tank, liquid level is controlled at the same height.


    The parameters are adjustable, simple and convenient, and the filling dose can be accurately calibrated, controlled within 0.5% of the filling dose. The machine is made of high quality stainless steel, beautiful appearance, will not pollute the material, is the best choice of both high viscosity and normal liquid filling.


    Bottling Filling Machine is realized by the man-machine dialogue interface under the operation and control of high-speed PLC. It realizes the linear stepless speed regulation transmission through the human-machine dialogue interface, and can adjust the filling capacity arbitrarily. It can be equipped with a pneumatic gland or a capping device to form a multi-station one-machine multi-functional production line.


    The filling machine assembly line integrates machine, electricity and gas into one, with unique design, complete functions, stable performance, high quality and beautiful appearance. Applied to GMP standard. Easily dismantle, clean and maintain. The whole machine is safe, environmental, sanitary, adapting to various kinds of working place.

    Piston liquid filling machine is widely used for bottling of beverage, daily chemical, agricultural chemical, food and pharmaceutics industry.


    Automatic 50-1000ml Pneumatic Driving Piston Filling Machine



    Technical Parameters
    Model
    HYPF-1000P-6
    HYPF-1000S-8
    HYPF-1000S-12
    HYPF-1000S-16
    HYPF-1000S-20
    Heads
    6
    8
    12
    16
    20
    Capacity(BPH)
    200ml: ≤3000
    200ml: ≤3500
    200ml: ≤5000
    200ml: ≤6500
    200ml: ≤7500
    Volume
    50-1000ml
    Accuracy
    ≤1000ml: ±2ml; 100-500ml: ±1ml; ≤100m: ≤1ml
    Suitable Bottles
    Height: 100-280mm, Diameter: Φ30-110mm
    Control method
    Touch screen and PLC
    Air supply
    0.5-0.7Mpa
    Voltage
    415V/380V/220V, Three Phases , 50/60Hz, customized globally

    Main Features


    1) Simple structure in linear type, easy in installation and maintenance.

    2) Adopting advanced world famous brand components in pneumatic parts, electric parts and operation parts.

    3) This filling machine is a high-tech filling equipment controlled by microcomputer PLC programmable, equip with photo electricity transduction and pneumatic action.

    4) Accurate measurement: adopt servo control system, ensure the piston can always reaches constant position.

    5) There is anti-leakage tray after nozzles, prevent the liquid drop on conveyor cause pollution.

    6) Convenient adjustment: replacement filling specifications only by a handle wheel.

    7) Suitable material: cream, gel, Oil, jams, sauce, daily chemicals, and something that very viscous.



    Machine Display



    Automatic 50-1000ml Piston Filling Machine


    Automatic 50-1000ml Pneumatic Driving Piston Cylinder Dosing Type Filling Machine


    Automatic 50-1000ml Filling Machine


    Automatic 50-1000ml Piston Filling Machine


    Automatic 50-1000ml Filling Machine Details


    Automatic Pnuematic Filling Machine


    Automatic 50-1000ml Piston Filling Machine logistics
