  • HYHM-R Automatic Rotary OPP and BOPP Label Hot Melt Glue Labeling Machine
  • HYHM-R Automatic Rotary OPP and BOPP Label Hot Melt Glue Labeling Machine
  • HYHM-R Automatic Rotary OPP and BOPP Label Hot Melt Glue Labeling Machine
  • HYHM-R Automatic Rotary OPP and BOPP Label Hot Melt Glue Labeling Machine
HYHM-R Automatic Rotary OPP and BOPP Label Hot Melt Glue Labeling MachineHYHM-R Automatic Rotary OPP and BOPP Label Hot Melt Glue Labeling MachineHYHM-R Automatic Rotary OPP and BOPP Label Hot Melt Glue Labeling MachineHYHM-R Automatic Rotary OPP and BOPP Label Hot Melt Glue Labeling Machine

HYHM-R Automatic Rotary OPP and BOPP Label Hot Melt Glue Labeling Machine

  • Product Item:HYHM-R
  • Label material: OPP / BOPP
  • Machinery Capacity: 8000-32000
  • Driven Type: Electric
  • Labeling glue: Hot melt glue
  • Automatic hot melt glue labeling machine , bopp opp label applicator , wine bottle hot melt glue labeling machine , tin can hot melt glue labeling machine
    Inquiry Send Email

    Description

    HYHM-R Automatic Rotary OPP and BOPP Label
    Hot Melt Glue Labeling Machine


    Product Introduction

    This hot melt adhesive OPP labeling machine is a new type of rotary and continuous labeling machine. The equipment can automatically adjust the inlet and outlet transmission of the container; The containers conveyed by the conveyor belt are separated by a certain distance by the bottle separating screw according to the spacing of the star wheels, then the imported star wheels convey the containers to the container turntable, and after the containers are fixed by the bottle pressing mechanism and the mold base of the containers, the containers start to rotate at a certain speed; Mechanical pre-positioning in the process of product rotation; And carry out positioning and labeling according to the track of the mechanism.
    When the container reaches the electric eye detection position, the computer host controls the label delivery system to deliver the label, and after a label delivery action is completed, the high-speed cutter cuts off a label; Because Sanyo small inertia high-speed servo motor is adopted, the accuracy and stability of high-speed bid sending and cutting are ensured.
    The cut label is sent to the gluing system; In this part, the system glues the front and rear edges of the label, which makes the consumption of hot melt adhesive the lowest.
    When the glued label is turned to the labeling position, the label can be accurately and effectively adhered to the container. Because the container is in a rotating state during the label conveying process, the label can be stably and tightly attached to the container. The adhesive tape at the glue tail can form a good label lap seal, thus completing a labeling process. Suitable for labeling OPP/bopp hot melt adhesive, film label, paper-plastic composite film, label, paper label on plastic, metal, glass and other round containers. Labeling stations: 12, 15, 18, 24, 30, can be specially designed according to customer requirements.

    Product Application
    Labels: labels of various rolled materials such as 0PP, pearl film and composite paper.
    Application: Round, square, flat cylindrical containers and canned OPP ring labeling are required.
    Application: Widely used in washing, beverage, mineral water, food and other industries.
    Application examples: Automatic hot melt glue labeling machine, bopp / opp label applicator, wine bottle hot melt glue labeling machine, tin can hot melt glue labeling machine, aluminum can hot melt glue bopp / opp label applicator, glass bottle hot melt glue bopp / opp labeling machine, beverage pet bottle hot melt glue label  applicator, plastic bottle hot melt glue label applicator, etc.

    HYHM-R Automatic Rotary OPP and BOPP Label Hot Melt Glue Labeling Machine

    HYHM-R Automatic Rotary OPP BOPP Hot Melt Glue Bottles Labeling Machine

    Technical Parameters
    Labeling heads
    12, 15, 18, 24, 30pcs
    Labeling capacity
    8000-32000pcs/hour
    Labeling glue
    Hot Melt Glue
    Glue temperature
    120~160℃
    Labeling accuracy
    ±0.5 mm
    Label material
    OPP / BOPP
    The inner diameter of label roll
    152 mm
    The outer diameter of label roll
    600 mm(max)
    The suitable size of label
    Width 40-210 mm, length 300 mm (max)
    The suitable size of labeling objects
    Can be customized
    Operating direction
    Left or Right
    Air pressure
    0.6Mpa
    Total Power
    8kw
    Power supply
    AC220V/380V/415V/440V, Three phases. Globally customized
    Net weight
    About 1900kg
    Machine size
    190×200×200cm
    Automatic Rotary OPP and BOPP Hot Melt Glue Labeling Machinery

    HYHM-R Automatic Rotary BOPP Label Hot Melt Glue Applicator

    Automatic Rotary BOPP Label Hot Melt Glue Bottle Labeling Machine

    HYHM-R Automatic Rotary OPP Label Hot Melt Glue Labeling Machine

    Automatic Rotary BOPP Label Hot Melt Glue Labeling Machinery

    HYHM-R Automatic Rotary OPP Label PET Bottle Hot Melt Glue Labeling Machine

    Automatic Rotary OPP Label Beverage Bottle Hot Melt Glue Labeling Machine

    Automatic Rotary OPP and BOPP Label PET Bottle Hot Melt Glue Labeling Machine

    Automatic Rotary OPP and BOPP Hot Melt Glue Labeling Machine
