  • HYRO-A100 Automatic Servo Rotor Pump Single Head Filling Machine
  • HYRO-A100 Automatic Servo Rotor Pump Single Head Filling Machine
  • HYRO-A100 Automatic Servo Rotor Pump Single Head Filling Machine
  • HYRO-A100 Automatic Servo Rotor Pump Single Head Filling Machine
HYRO-A100 Automatic Servo Rotor Pump Single Head Filling MachineHYRO-A100 Automatic Servo Rotor Pump Single Head Filling MachineHYRO-A100 Automatic Servo Rotor Pump Single Head Filling MachineHYRO-A100 Automatic Servo Rotor Pump Single Head Filling Machine

HYRO-A100 Automatic Servo Rotor Pump Single Head Filling Machine

  • Product Item:HYRO-A100
  • Control: PLC+ Touch Screen
  • Machinery Capacity: 1000-2000BPH
  • Material: US304/316 Stainess Steel
  • Marketing Type: Ordinary Product
  • sesame seasoning oil dispenser , hotpot base filling equipment , vegetable paste filling machine
    Inquiry Send Email

    Description

    HYRO-A100 Automatic Single Head Servo Rotor Pump Filling Machine
    Product Introduction
    Linear Servo Rotor Pump filling machine is for different viscous liquid and cream with different bottle or jars. The performance of the product reaches the international leading level. PLC control, servo rotor pump dosing, equipped with brand touch screen, smooth operation, no leakage phenomenon, No bottle no filling, automatically control feeding the liquid into machine tank, liquid level is controlled at the same height.
    The parameters are adjustable, simple and convenient, and the filling dose can be accurately calibrated, controlled within 0.5% of the filling dose. The machine is made of high quality stainless steel, beautiful appearance, will not pollute the material, is the best choice of both high viscosity and normal liquid filling. Its hopper is matched with water circulation heating and stirring function, which can be used for granules sauce, thick Cream.
    Bottling Filling Machine is realized by the man-machine dialogue interface under the operation and control of high-speed PLC. It realizes the linear stepless speed regulation transmission through the human-machine dialogue interface, and can adjust the filling capacity arbitrarily. It can be equipped with a pneumatic gland or a capping device to form a multi-station one-machine multi-functional production line.
    The filling machine assembly line integrates machine, electricity and gas into one, with unique design, complete functions, stable performance, high quality and beautiful appearance. Applied to GMP standard.
    Easily dismantle, clean and maintain. The whole machine is safe, environmental, sanitary, adapting to various kinds of working place.
    Piston liquid filling machine is widely used for bottling of beverage, daily chemical, agricultural chemical, food and pharmaceutics industry.

    Product application
    10-1000ml customized single-head liquid rotor pump dosing filling machine.
    For examples: Chili sauce filling machine, Beef paste filling machine, Mushroom sauce filling machine, Granuled sauce dispensing equipment, Soybean sauce filling machine, Pepper chili filler, sesame seasoning oil dispenser, hotpot base filling equipment, vegetable paste filling machine, meat soap dispenser, etc.
    Any liquid, half-flowing liquid, viscous cream, with or without granules, sauce dispenser, liquid filler, refill equipment, Vaseline filling machine, paraffin wax filler, hand sanitizer filler, facial cream filler, etc.

    HYRO-A100 Automatic Single Head Servo Rotor Pump Filling Machine

    single head servo rotor pump sauce filling machine

    Technical Parameters
    Model
    HYRO-A100
    Heads
    1pc
    Capacity(BPH)
    200ml: Approx 1200
    Volume
    5-1000ml customized ( can fill more )
    Accuracy
    ≤±0.5%
    Suitable Bottles
    Height: 100-280mm, Diameter: Φ30-110mm, (can be customized)
    Control method
    Touch screen and PLC
    Air supply
    0.5-0.7Mpa
    Volume of hopper
    40L/80L optional
    Power supply
    1500w
    Voltage
    110V/220V, Single-phase , 50/60Hz, customized globally
    HYRO-A100 Automatic single head servo rotor pump filler

    Automatic single head servo rotor pump liquid filling machine

    HYRO-A100 Automatic single head servo rotor pump cream filling machine

    HYRO-A100 Automatic single head servo rotor pump granuled sauce filling machine

    Automatic single head servo rotor pump sauce filling machine

    Automatic single head servo rotor pump filling machine
