  • HYT-60 Semi-automatic Non-dry Glue Self-Adhesive Sticker Flat Surface Plane Labeling Machine | Label Applicator
  • HYT-60 Semi-automatic Non-dry Glue Self-Adhesive Sticker Flat Surface Plane Labeling Machine | Label Applicator
  • HYT-60 Semi-automatic Non-dry Glue Self-Adhesive Sticker Flat Surface Plane Labeling Machine | Label Applicator
  • HYT-60 Semi-automatic Non-dry Glue Self-Adhesive Sticker Flat Surface Plane Labeling Machine | Label Applicator
HYT-60 Semi-automatic Non-dry Glue Self-Adhesive Sticker Flat Surface Plane Labeling Machine | Label ApplicatorHYT-60 Semi-automatic Non-dry Glue Self-Adhesive Sticker Flat Surface Plane Labeling Machine | Label ApplicatorHYT-60 Semi-automatic Non-dry Glue Self-Adhesive Sticker Flat Surface Plane Labeling Machine | Label ApplicatorHYT-60 Semi-automatic Non-dry Glue Self-Adhesive Sticker Flat Surface Plane Labeling Machine | Label Applicator

HYT-60 Semi-automatic Non-dry Glue Self-Adhesive Sticker Flat Surface Plane Labeling Machine | Label Applicator

  • Product Item:HYT-60
  • Label accuracy: ≤±1mm
  • Machinery Capacity: 600-1800BPH
  • Objects: Bottle, box, cap, pouch, etc.
  • Marketing Type: Ordinary Product
  • plastic shell sticker labeling machine , flat boxes label applicator , book surface labeling machine , cream lid top label applicator
    Inquiry Send Email

    Description

    HYT-60 Semi-automatic Non-dry Glue Self-Adhesive Sticker
    Top Surface Plane Labeling Machine
    Introduction
    Semi-automatic Desktop Plane Sticker Labeling Machine Suction-attaching method is used for labeling, achieving plane labeling on various product, such as cosmetics flat bottles, packaging boxes, plastic cover and so on.
    Suitable for uneven surface labeling by changing the label overlaying mechanism, such as the labeling on concave surface and circle-arc surface.
    Suitable for labeling on various irregular-shaped bottle by changing fixtures.
    Optional ribbon print coder or ink-jet printer, to print production date and batch number on the label, achieving coding -labeling integration.

    Semi-automatic plane label applicator is widely used daily chemical, agricultural chemical, food, personal care and pharmaceutics industry.


    Operation process
    Manual operation:
    put bottle to the machine→press foot switch→press top mechanism go down, press the bottle→come out a label→labeling→standard labeled→press top mechanism go up→take out the bottle
    Automatic operation:
    put bottle to the machine→test object electric eyes detect has a bottle in place→press top mechanism go down, press the bottle→come out a label→labeling→standard labeled→press top mechanism go up→take out the bottle

    Application

    Desktop flat surface labeler, Semi-automatic plane labeling machine, packaging box plane label applicator, bottle caps label applicator, plastic shell sticker labeling machine, flat boxes label applicator, book surface labeling machine, cream lid top label applicator, electronic component top surface label applicator etc.

    HYT-60 Desktop Flat Surface Semi-automatic Labeling Machine

    Technical Parameters
    Labeling capacity
    0~30pcs/min
    Labeling accuracy
    ±1 mm
    Label material
    Adhesive sticker
    The inner diameter of label roll
    76 mm
    The outer diameter of label roll
    240 mm(max)
    The suitable size of label
    Width 15-150 mm, length 15-100 mm
    The suitable size of labeling objects
    Width 20-150 mm, Length 20-200 mm, Thickness: 0.2mm ~ 120mm
    Total Power
    60w
    Power supply
    AC220V/110V, Single phase. Globally customized
    Net weight
    About 35kg
    Machine size
    55(L)x35(W)x60(H)cm
    HYT-60 Desktop Flat Surface Semi-automatic Labeler

    Table Top Flat Surface Semi-automatic Labeler

    HYT-60 Table Top Flat Surface Semi-automatic Labeling Machine

    Table Top Flat Surface Semi-automatic Label Applicator

    Table Top Flat Surface Semi-automatic Bottle Label Applicator

    HYT-60 Table Top Flat Surface Pouch Semi-automatic Labeler

    HYT-60 Table Top Box Surface Semi-automatic Labeling Machine

    Table Top Cap Flat Surface Semi-automatic Labeler

    Desktop Bottle Flat Surface Semi-automatic Label Applicator

    HYT-60 Desktop Bottle Flat Surface Semi-automatic Labeling Machinery

    Desktop Bottle Flat Surface Semi-automatic Labeler

    HYT-60 Desktop Flat Surface Semi-automatic Labeling Machinery

    Desktop Flat Surface Semi-automatic Labeler
