HY-SPL-02 Lab-scale PVA Film Pod Sample Test Packing Machine
Product Description
Product Introduction
It is a semi-auto lab-scale machine used for making small unit dose water soluble capsules samples of different kinds of non-aqueous chemical preparation (detergent,
pesticide, fertilizer…). It has good adaptability of water soluble PVA film. Machine provide function of vacuum absorb film in the mold, heating sealing film. Operator puts film, fill material ( powder, liquid, granules), fetch pod, cut pod.
Product Application
The machine is particularly suitable for packing non-water washing detergent, missible oil, pesticide oil, chemicals agent and some other non aqueous system contents small dose single packs. It is a preferred packing way of sample pod.
For examples: Single color laundry detergent pod sample packing machine, two colors washing detergent pod sample packer, three chambers pva laundry detergent powder bead sample packing machine, Fragrance beads pva pod sample test packing machine, etc.
HY-SPL-02 Lab-scale PVA Film Pod Sample Test Packing Machine
|
Technical Parameters |
|
|
Mould cavity arrangement |
1-4 chambers |
|
Packing speed |
approx 50pcs per hour |
|
Volume |
5-30 ml by changing mould |
|
Voltage |
AC110V/220V/240V, one phase, Globally customized |
|
Power |
1kw |
|
Pneumatic |
0.6 mpa |
|
Sealing system |
Sealing temperature range50-200℃，Accuracy±1℃ |
|
Water |
Manually adding |
|
Roll film material |
PVA (PVOH) Film |
|
Vacuum system |
Can independent provide vacuum degree from -0.01 to -0.05MPa |
|
Difference to model HY-SPL-001 |
Its sealing part is embossed, and it has pulling mold out function from pressing position. |
|
Weight |
50kg |
|
Machine size |
L55×W50×H70cm |
Main Features
1) Simple structure in horizontal type, easy in installation and maintenance.
2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.
3) Accurate measuring to get excellent packing effect.
4) Running in a semi-automatic method, and intellectualization, no pollution
5) Specially designed for detergent pod sample packed in PVA film.
6) Economical price, suitable for lab test.
